Brochure
MAINLY USED IN
Mining/Quarry
Infrastructure Construction
-
OPERATING WEIGHT
79.1 ton
-
BUCKET CAPACITY (SAE HEAPED)
5.24 m³
-
ENGINE POWER (SAE J1349, NET)
546.7/2,100 kW/rpm
Specifications
| Classification | DX800LC-7 |
|---|---|
| Operating Weight | 79.1 ton |
| Bucket Capacity (SAE HEAPED) | 5.24 m³ |
| Engine Power (SAE j1349, net) | 546.7/2,100 kW/rpm |
| Engine Model | Perkins 2506J |
| Travel Speed | 4.8/2.9 km/h |
| Max. Digging Reach | 11,595 mm |
| Max. Digging Depth | 7,120 mm |
| Max. Digging Height | 10,470 mm |
| Overall Length | 12,320 mm |
| Overall Width | 3,560 mm |
| Overall Height | 5,125 mm |
Compare
Products
Products
| Classification |
|---|
| Operating Weight |
| Bucket Capacity (SAE HEAPED) |
| Engine Power (SAE j1349, net) |
| Engine Model |
| Travel Speed |
| Max. Digging Reach |
| Max. Digging Depth |
| Max. Digging Height |
| Overall Length |
| Overall Width |
| Overall Height |
| DX800LC-7 |
|---|
| 79.1 ton |
| 5.24 m³ |
| 546.7/2,100 kW/rpm |
| Perkins 2506J |
| 4.8/2.9 km/h |
| 11,595 mm |
| 7,120 mm |
| 10,470 mm |
| 12,320 mm |
| 3,560 mm |
| 5,125 mm |
