MAINLY USED IN
Mining
Mining/Quarry
OPERATING WEIGHT
18,900 kg
BUCKET CAPACITY (SAE HEAPED)
3.5 m³
ENGINE POWER (SAE J1995 GROSS)
178 kW (240PS) @ 2,000 rpm
PRODUCTIVITY & PERFORMANCE
· The perfect blend of efficiency and power. The engine produces 178 kW at rated rpm. High power and impressive torque range enables to precisely deliver the stable working speed.
· With 3,400mm wheel-base and small turning radius of 6,058mm, designed for greater agility of movement and more efficient operation.
REASONABLE AND PRACTICAL VETERAN
· Hydraulic system adopts double-pump confluence technology to make full use of power and energy.
NEW LOOK & ENHANCED STRUCTURE
· Applied new look with streamlined appearance and reinforced structure. With newly added LED lamp, SD350-2'S design represent a bold and functional brand style.
RELIABILITY AND DURABILITY
· The advanced DEVELON drive axle and improved differential gear process have increased gear flexural strength, enhanced the reliability of the drive axle and extended its lifespan.
OPERATOR COMFORT
· Newly designed cabin is spacious and provides wider view and enhanced safety, with low noise & vibration levels and excellent all-round visibility.
Classification | SD350-2 |
---|---|
Operating Weight | 18,900 kg |
Bucket Capacity (SAE HEAPED) | 3.5 m³ |
Engine Power (SAE J1995 Gross) | 178 kW (240PS) @ 2,000 rpm |
Engine Model | Weichai WP10G240E343 |
Height at Bucket Pivot Point | 4,303 mm |
Breakout Force | 197 kN |
Turning Radius at Tire Center | 6,058 mm |
Tires | 23.5-25-20PR |
Overall Length | 8,540 mm |
Overall Width | 3,035 mm |
Overall Height | 3,450 mm |
Static Tipping Load(straight) | 14,800 kg |
Classification |
---|
Operating Weight |
Bucket Capacity (SAE HEAPED) |
Engine Power (SAE J1995 Gross) |
Engine Model |
Height at Bucket Pivot Point |
Breakout Force |
Turning Radius at Tire Center |
Tires |
Overall Length |
Overall Width |
Overall Height |
Static Tipping Load(straight) |
SD350-2 |
---|
18,900 kg |
3.5 m³ |
178 kW (240PS) @ 2,000 rpm |
Weichai WP10G240E343 |
4,303 mm |
197 kN |
6,058 mm |
23.5-25-20PR |
8,540 mm |
3,035 mm |
3,450 mm |
14,800 kg |
